Cylindrical Reed Sensor

Cylinder Reed sensors are widely used to the security system , household application ,Auto and so on.

The size is smaller than rectangular reed sensor , fixed by the glue or put in a hole .Matching different magnet, the sensing distance range from 5mm to 30mm is available.

MS08's size is bigger than MS07 and MS18 ,It has normal open (N/O),normal closed (N/C) and changeover three types can choice .

MS07 is a small cylindrical ,ABS housing to protect the inner reed switch.

MS18 has the smallest size , . Widely be used to communication field .

Size : MS07 Diameter 4*18mm

MS08 Diameter 5.6*25.6mm

MS18 Diameter 3*10mm

MS20's is similar size with MS08.MS21 and MS20 can realize the same function as the MS08.

They are designed to work in a high voltage and power environment .

Szie :MS20 : Diameter 6*30mm

MS21 : Diameter 11*15mm;Diameter 11*30mm

Feature:

§ Being hermetically sealed ,It can be used in all types of environments including air ,water ,vacuum ,

§ oil,fuels and dust laden atmospheres

§ No power required or current drain in its quiescent state

§ Choice of normal open(Form A) ,normal closed(Form B) ,or change-over contact(Form C)

§ Customer can define sensitivity ,cable length and connector

Application

§ Household application

§ Security system switch

§ Level sensor

§ Position and end switch

Electrical Characteristics:
